HD-SDI-BOX

HD-SDI-BOX


High-Definition Serial Digital Interface, long distance signal transmission
box (Master/ Slave) up to 100M, video i HD-SDI-BOX nput format 720p/1080i
Features Long Distance and High Quality BOX Marketing Application
Specifications I/O Interface Packing List
Ordering Information

  Features


High-definition serial digital interface (HD-SDI) transmission box support 720p 1080i video resolution
Long distance signal transmission up to 100M, add additional HD-SDI-BOX-S to extend the transmission distance
HD-SDI-BOX-M convert VGA /HDMI to HD-SDI
HD-SDI-BOX-S convert HD-SDI to HDMI
Remote touch control link
Uncompressed transmission
Applications: Broadcasting, Video transportation
  Long Distance and High Quality BOX

The HD-SDI-BOX kit, combining the HD-SDI-BOX-M (Master) and the HD-SDI-BOX-S (Slave), provides a high-definition serial digital interface (SDI) for long distance signal transmission. With the HD-SDI-BOX kit, the HDMI or VGA video signal can be transmitted directly through a 100m coaxial cable without compression. The HD-SDI-BOX kit also supports touch-screen remote control. The touch-screen remote control is linked through the RJ-45 Cat5 cable and RS-232 cable.


  Marketing Application

Using one HD-SDI-BOX Master and two HD-SDI-BOX Slave systems to connect to PC and display device for up to 200 m long distance signal transmission. The user can extend the connection distance by adding more HD-SDI-BOX Slave systems. Adding one HD-SDI-BOX Slave system can extend 100 m ~ 300 m for HD or SD video quality.

  Specifications


Model Name

HD-SDI-BOX-M-R10

HD-SDI-BOX-S-R10

Input

1 x HDMI (No support HDCP), 1 x VGA

1 x HD-SDI

Output

1 x HD-SDI

1 x HD-SDI Loop Through, 1 x HDMI

I/O Panel

Front:
1 x HDMI
1 x VGA IN
2 x LED (HDMI, VGA)
1 x Button for HDMI, VGA Select
1 x RS-485
1 x Power LED

Front:
1 x HD-SDI IN
1 x RJ-45 Control In for remote touch link
1 x RS-232
1 x Touch ON/OFF switch
1 x Power LED

Rear:
1 x HD-SDI OUT
1 x RJ-45 Control Out for remote touch link
1 x RS-232 for Touch Control
1 x DC input

Rear:
1 x HD-SDI Loop Through
1 x HDMI Out
1 x Control Out
1 x RS-232 Touch
1 x DC input

Supported Mode

Video mode:
720p (1280 x 720 @ 50/ 60Hz)
1080i (1920 x 1080 @ 50/ 60Hz)
PC mode:
1280 x 720 @ 50Hz/ 60Hz
1920 x 1080 @ 50/ 60Hz

Output
Video mode:
720p (1280 x 720 @ 50/ 60Hz)
1080i (1920 x 1080 @ 50/ 60Hz)
PC mode:
1280 x 720 @ 50Hz/ 60Hz
1920 x 1080 @ 50/ 60Hz

Datarate

1.5Gb/s

1.5Gb/s

Power

Power Supply: 5V, 5A
Power Consumption: 5W

Power Supply: 5V, 5A
Power Consumption: 4W

Dimensions

136 mm x 103 mm x 32 mm

136 mm x 103 mm x 32 mm

Power Adapter

Input: 90VAC to 264VAC/47Hz to 63Hz
Output: 5V DC

Input: 90VAC to 264VAC/47Hz to 63Hz
Output: 5V DC


  I/O Interface

HD-SDI-BOX-M-R10

HD-SDI-BOX-S-R10


  Packing List


1 x HD-SDI-BOX set (Including Master and Slave box)
2 x EU power cord for master and slave box
2 x 5V adaptor for master and slave box
4 x Wall mounting bracket
8 x Screw
1 x User manual
  Ordering Information


Part No. Description
HD-SDI-BOX-R10 High-Definition Serial Digital Interface, Long distance signal transmission box (Master/ Slave) up to 100M, video input format 720p/1080i
HD-SDI-BOX-M-R10 High-Definition Serial Digital Interface, Long distance signal transmission Master box up to 100M
HD-SDI-BOX-S-R10 High-Definition Serial Digital Interface, Long distance signal transmission Slave box up to 100M
